$39,500

EZ-SCREEN 1200XL

---

VALUABLE LESSONS IN THE NEW MATH OF PRODUCTIVITY AND VERSATILITY

It’s simple math: whether working with topsoil, compost, or gravel, ordinary box screeners can’t work as hard as the EZ-Screen 1200XL.  Unless they’re teamed up with two loaders.

The reason is the 1200XL’s built-in conveyor system.

With a typical box screener, the loader operator has two jobs. Job one is keeping the screener filled with material.  Job two is scooping out the fines and moving them to the stockpile.

Put the 1200XL on the site and the loader operator has just one job: loading the screener.  Moving fines is handled by the 24” wide conveyor that stockpiles material as high as nine feet – into a waiting truck.  Think what that can do for productivity.

So here’s the new math: one EZ-Screen 1200XL plus one loader equals a competitive screener and two loaders.

The 1200XL can be equipped with a variety of woven wire and piano screens.  One day it can be a topsoil screener, the next a gravel screener, and the day after a compost screener.

Another New Math Lesson:

$9,500 Optional Middle Product Conveyor**
Boost production capabilities even higher as this option permits the production of three different end products at the same time.

---

EZ-1200XL SPECIFICATIONS

• Loading bucket size range is 1/2 to 1-3/4 yards with 8′ feed height
• 6′ x 5′ double-deck end tensioned-screens
• The top deck is equipped with woven screen cloth and the bottom deck can be fitted with either a woven or piano wire screen.
• Hundreds of different screen combinations available
• Kohler air-cooled diesel; 25-HP hour meter and electric starting system standard
• “Spiral Wound” sealed battery for long life in a vibratory environment
• Triple-stage air filter system with pre-cleaner standard
• Fully enclosed, lockable engine compartment and starter panel
• Patented non-hydraulic Kinetic Drive Recovery System
• Hydraulically driven 24″ wide conveyor with 9′ dump height
• Conveyor components are U.S. made, CEMA “B” grade
• Conveyor belt is “endless”, or vulcanized for long life
• All EZ-Screen surfaces have a baked-on powder coat finish
• Custom-made sealed wiring harness with lights for legal towing
• Tow hitch has safety chains, break-away controller and battery; Hitch raised and lowered hydraulically
• 7,000-lb. capacity E-Z lube axle on rear with hydraulic activated rear pivoting assembly with electric brakes, 235/85R16 “E” range 10-ply trailer tires plus detachable mudflaps

Download the EZ-1200XL Brochure!

EZ-1200XL Brochure File Type: PDF File Size: 568KB	EZ-1200XL working in SK, Canada File Type: PDF File Size: 117KB
EZ-1200XL with Middle Product Conveyor File Type: PDF File Size: 436KB	National Golf Club, AU File Type: PDF File Size: 108KB
Hazardous Duty File Type: PDF File Size: 307KB
